Aluminium Insulated Panels

Finish Facades’ aluminium insulated spandrel panels are designed as part of your curtain walling system, obscuring walling and flooring systems to complete your cladding.

High quality, lightweight, and easy to install, Finish Facades’ aluminium insulated spandrel panels work in conjunction with your cladding to conceal exposed building systems.

Spandrel panels boast the advantages of being thermally efficient, providing insulation and weather resistance.

Manufactured as part of our bespoke facade systems, your project requirements dictate the specifications of the panels - we cater to all high end projects, from new build to fire remediation, for all buildings and sectors.

With decades of experience supporting us, the Finish Facades team work closely with architects and installers from initial consultation through to the finished product, to ensure we not only work in line with industry regulations but also your architectural visions.

Fire Rated Aluminium Spandrel Panels

Fire performance requirements for external wall systems vary depending on factors such as the building’s use, height and construction. Approved Document B sets out the circumstances in which materials used within external walls should achieve an A1 or A2-s1, d0 reaction-to-fire classification.

Finish Facades’ aluminium insulated spandrel panels are tested to BS EN 13501-1 and are available with A1 or A2-s1, d0 classifications, depending on the panel specification and finish.

The panels have also been tested to CWCT standards for impact and wind resistance, helping to demonstrate their performance as part of the wider facade system.

Fire Rated Spandrel Panel FAQs

What is a fire rated spandrel panel?

A fire rated spandrel panel is used within a curtain walling or facade system to conceal structural elements between floors while providing a specified reaction-to-fire classification. Finish Facades’ FINSPAN aluminium insulated spandrel panels are available with A1 or A2-s1, d0 classifications to BS EN 13501-1, depending on the panel specification and finish.

What do the A1 and A2-s1, d0 fire classifications mean?

Under BS EN 13501-1, A1 is the highest reaction-to-fire classification and identifies a product as non-combustible. A2-s1, d0 indicates limited combustibility, with very limited smoke production and no flaming droplets or particles. The correct specification should be selected according to the building type, height and applicable fire-safety requirements.

Are FINSPAN panels suitable for fire remediation projects?

Yes. FINSPAN fire rated spandrel panels can be specified for both new-build developments and facade remediation projects. Each panel is manufactured to suit the project requirements, helping replace unsuitable existing materials while maintaining the required appearance, insulation and weather performance. The suitability of the complete external wall build-up should always be assessed for the individual project.

Are aluminium spandrel panels tested for fire performance?

FINSPAN aluminium spandrel panels are tested and classified to BS EN 13501-1 through UKAS-accredited testing facilities. Depending on the panel construction and finish, the range includes A1 and A2-s1, d0 options. Project-specific classification and test documentation should be reviewed during specification.

Do fire rated spandrel panels also provide insulation?

FINSPAN aluminium insulated spandrel panels combine the external aluminium facing with an insulated panel construction. This helps conceal floor slabs and other structural elements while supporting the thermal performance and visual continuity of the curtain walling system. Panel depths are available from 20mm to 200mm to meet different project requirements.

The Perfect Finish

With our range of finishing options, including polyester powder coating, pre-coated material and anodising, we ensure your spandrel panels are finished to perfection.

Finishing not only reinforces the durability of panels against environmental corrosion and general wear and tear, but determines the look of the panel in your curtain walling system.

Finish Facade’s polyester powder coating is available in all RAL colours to complement the surrounding facade on your building, achieving a A2-s1, d0 fire rating.

Our anodised and pre-coated aluminium spandrel panels achieve an A1 rating, with a selection of colours to choose from.

Reach out to Finish Facades for your Spandrel Panel needs

At Finish Facades, we provide bespoke, aluminium insulated spandrel panels for your commercial or residential projects. Choosing from many types of cladding can be a lengthy task, we can help advise you in picking the best cladding option for your project.

With a wide range of high-quality finishing options and a reliable turnaround time, reach out to us for costs and more information.
